Do battery cabinets have top clearance?

Battery cabinets are frequently criticized for their lack of top clearance. For example, in a cabinet containing multiple strings of low ampere-hour batteries, there might be several shelves, each with one string of cells. The cell units on each shelf might be arranged two, three, or more cells deep.

Why do you need a battery cabinet?

Ease of use is one of the principle selling points for battery cabinets. It is convenient to service the equipment when the UPS and the battery (ies) are right next to each other. Conversely, it is inconvenient to have to go to a separate room when open-rack batteries are installed.

Can you put a battery in an electrical room?

Local or regional codes may dictate whether batteries are permitted in an electrical room. Smaller UPS systems (e.g, up to 250 kVA) are commonly installed directly in the computer room along with their respective battery cabinets. The UPS and/or battery cabinets might be configured to look like standard computer equipment racks.

How many cells can a battery cabinet hold?

One cabinet should be able to hold at least one complete string of cells. Best practice is that strings should not be split between two cabinets in order to ensure reliability of the entire string. Figure 1 - Battery cabinet with top terminal cells

Do battery cabinets need to be locked?

Battery cabinets must enclose the batteries behind locked doors accessible only to authorized personnel. As long as the cabinets are kept locked, they can be located in a computer room or other rooms accessible by non-battery technicians.

Can a battery be installed in a computer room?

Sometimes they are installed in the same room as the UPS (i.e., electrical equipment room). Local or regional codes may dictate whether batteries are permitted in an electrical room. Smaller UPS systems (e.g, up to 250 kVA) are commonly installed directly in the computer room along with their respective battery cabinets.
